Project Name: Ä°stanbul Water Supply Project Master Plan and Feasibility Studies for Istranca Creeks
Country: TURKEY
Finance Source: Government
Tags: Turkey, Government funded, Municipal Infrastructure, Master Plan, Feasibility Study, Mapping
The purpose of the project is to provide drinking and domestic water for Ä°stanbul from Istranca Creeks for a population of 3 000 000. Project area is 1300 km² and a total of 289.5×106 m3/year water can be utilized by constructing 4 dams and 12 diversion weirs. Flows of Istranca Creeks will be conveyed to Terkos Lake and from there water will be pumped to the treatment plants. Three regions for basin development of Istranca Creeks are planned as follows:
|  | Kıyıköy Region: | Demirköy Region | Balaban Region |
| Dams | Kıyıköy I and Kıyıköy II Dams | Demirköy Dam | Balaban Dam |
| Conveyance Lines | L= 45 km, D= 2200 mm-2950 mm
L= 26 km, D= 2200 mm-2600 mm L= 16 km, D= 1600 mm-1100 mm  |
L= 22 km, x1800 mm                        L= 30 km, 800 mm-1200 mm | L= 11 km, D= 1300 mm |
| Tunnel | D= 3.5 m, L= 22 km | D= 3.0 m, L= 3.9 km | D= 3.0 m, L= 3.55 km |
| Pump Station |
2900 kw |
 | 1000 kw |
| Number of Diversion weirs | 7 | 4 | Â |
| Pumping Line |
L= 3.4 km, 2×1700 mm |
 | L= 0.4 km, 1100 mm |
Â
The services provided within the scope of the project cover:
– Master Plans
– Feasibility studies
– Foundation investigations
– Investigations for construction materials
– Topographical mapping.
Special hydraulic modelling software for the project is developed by TEMELSU.
