Manavgat Dam and Hydroelectric Power Plant – Turkey

Project Name: Manavgat Dam and Hydroelectric Power Plant

Country: TURKEY

Client: Kepez Electricity Co.

Finance Source: Local

Tags: Turkey, Local, HEPP, Design

Manavgat Dam and HEPP is located on Manavgat River, 76 km east of the city of Antalya. Purpose of the project is to regulate peak flows released from Oymapınar HEPP which is situated in the upstream, so as to realize flood control; and to release a certain amount of water downstream in order to meet the downstream requirements for irrigation, tourism, fishing and sanitary needs during the hours when Oymapınar HEPP does not operate, as well as to produce 220 million kWh annually.

Main Features Of The Project:
Type of dam : Earth fill
Dam height : 29 m
Volume of dam body :1 200 000 m3
Volume of reservoir : 88 million m3
Spillway capacity : 4000 m3/s
Installed capacity : 2 x 24 MW

Reconnaissance studies, planning, feasibility study, final design, tender documents, consultancy and construction supervision have been implemented by Temelsu.
